The 17-200mm zoom lens is used in photoelectric pods and aiming systems, with bottom plate connection and strengthened design. It uses forward focusing, detects objects 8-10 km away, and has visible light and fog reduction modes. It's made of aluminum alloy, withstands 75g/6ms impact, and operates from -45°C to 70°C, even -55°C if needed.
The 17 - 200mm continuous zoom lens is primarily utilized in photoelectric pods or control aiming systems. This product employs a bottom plate connection, and the overall design mainly aims to enhance the structural strength.
A forward focusing structure is employed to compensate for the object distance and temperature. The observation vehicle can identify objects at a distance of 8 to 10 km. It features two observation modes: visible light and optical fog reduction.
The entire structure is crafted from aluminum alloy, capable of withstanding an impact strength of 75g/6ms. It can operate at temperatures as low as -40°C or even -45°C, and the high - temperature limit can reach 70°C. If necessary, it can function at -55°C.
| No. | Item | Param 1 | Param 2 | Param 3 | Note |
| 1 | Adaptive Camera pixel | 1920×1080 | 1920×1080 | 1920×1080 | |
| 2 | Pixel size(um) | 3.45 | 4 | 4.2 | |
| 3 | Format | 6.624×3.726 | 7.68×4.32 | 8.064×4.536 | |
| 4 | Camera diagonal size | 7.6 | 8.81 | 9.25 | |
| 5 | WFOV(°) | 22.05×12.51 | 25.46×14.48 | 26.69×15.20 | H×V |
| 6 | NFOV(°) | 1.90×1.07 | 2.20×1.24 | 2.31×1.30 | H×V |
| 7 | FOV(diagonal)(°) | 25.20～2.18 | 29.06～2.52 | 30.45～2.65 | Short focus～long focus |
| 8 | Focal length(mm) | 17～200 | |||
| 9 | F# | F3.8～F5 | |||
| 10 | Operating waveband | 400-700nm | 400-700nm | 400-700nm | |
| 750-950nm | 750-950nm | 750-950nm | |||
| 11 | Resolution(lp/mm) | 145 | 125 | 119 | |
| 12 | Optical max resolution (lp/mm) | 220 | 220 | 220 | |
| 13 | TOTR(mm) | 163.4 | 163.4 | 163.4 | |
| 14 | Maximum clear aperture (mm) | φ48 | φ48 | φ48 | |
| 15 | BFL(mm) | 23.85 | 23.85 | 23.85 | Filters included |
| 16 | Distortion | ≤1.5% | ≤2% | ≤3% | |
| 17 | Nearest working distance | 5m | 5m | 5m | |
| 18 | Focus | "Front group motorized focus" | "Front group motorized focus" | "Front group motorized focus" | |
| 19 | Focucing time | Customization | Customization | Customization | |
| 20 | Zoom | "Motorized continuous zoom" | "Motorized continuous zoom" | "Motorized continuous zoom" | |
| 21 | Zooming time | Customization | Customization | Customization | |
| 22 | Filter switching | Electric switching | Electric switching | Electric switching | |
| 23 | Maximum structural size (mm) | 85.5×84.5×170.1 | 85.5×84.5×170.1 | 85.5×84.5×170.1 | PCB not included |
| 24 | Weight (g) | <800 | <800 | <800 | |
| 25 | Motor voltage (V) | <12 | <12 | <12 | |
| 26 | Operating temperature | -40℃~70℃ | -40℃~70℃ | -40℃~70℃ | |
| 27 | Optical axis consistency | ≤2pixels | ≤2pixels | ≤2pixels |
